When your application isn't standard we design to your drawing. Every special is designed from your part or feature, spans 2–500 mm (0.079"–19.69"), repeats to 0.002 mm (0.0001"), and comes back from the design office as a proposed solution within 24 hours.

Internal Threads

A thread's pitch diameter hides between the crests, where no standard bore gauge can reach. Our thread heads carry profiled contacts that seat on the flank, reading pitch, major or minor diameter directly — 8–200 mm (0.315"–7.87"). Read our Three Minute Guide to Thread Measurement or contact our design office and we will get back with a design and solution in 24 hours.

Spherical Bores

A spherical bore is widest where a conventional gauge can't reach — past its own mouth. Our heads collapse to enter, then expand to read the true sphere diameter — 8–200 mm (0.315"–7.87"). Read our Three Minute Guide to Spherical Measurement or contact our design office and we will get back with a design and solution in 24 hours.

Ball Screws

A ball screw is measured where the balls actually run — on the track, not the crest. Our two- and three-ball contact heads seat in the groove exactly as the working balls do, built from your profile, pitch and ball diameter. Read our Three Minute Guide to Ball Screw Measurement or contact our design office and we will get back with a design and solution in 24 hours.

Internal Slots

Internal slots defeat round gauges — the feature is wider than its opening. Our heads enter through the narrow opening and gauge true slot width, plain, recessed or special-profile. Read our Three Minute Guide to Slot Measurement or contact our design office and we will get back with a design and solution in 24 hours.

Deep Bores

Honed cylinders, barrels and metre-deep housings are beyond any handheld gauge. Extensions carry the head to the measurement point, transducer near the anvils to cancel temperature error — proven past 4 m (13 ft), 50–300 mm (1.97"–11.81"). Read our Metrology Guide to Deep Bore Measurement or contact our design office and we will get back with a design and solution in 24 hours.

Internal Tapers

A taper has a different diameter at every depth, so where you measure matters as much as what. Our heads gauge diameter at a defined datum, with a clamp-ring method to verify the angle itself. Read our Three Minute Guide to Taper Measurement or contact our design office and we will get back with a design and solution in 24 hours.

O Ring Grooves

A groove diameter is always larger than the bore hiding it. Our heads pass through the entry bore, then extend contacts into the groove to read its true diameter — 8–200 mm (0.315"–7.87"). Read our Three Minute Guide to O-Ring Groove Measurement or contact our design office and we will get back with a design and solution in 24 hours.

Spline Bors

A spline bore has no single diameter — pitch, major and minor each need their own contact geometry. Our heads match your tooth form, odd or even counts, reading PCD, major or minor directly. Read our Three Minute Guide to Spline Measurement or contact our design office and we will get back with a design and solution in 24 hours.

MET-BRF-001
Design Office

Send us the drawing.

A design engineer responds within 24 hours. No drawing yet? You can describe the part instead.
